By applying 3D digital technologies we’ve positively transformed their training, workflows, quality control and maintenance.
3D Scanning used to create new parts for existing Roofbolter A roof bolter is a specialised machine designed for drilling holes and installation of safety bolts in roofs and walls of mines, power plants, tunnels and storage facilities. Challenge: Our client needed a digital twin of the existing machine so that new attachment pieces could…
Impeller Vanes Redesigned for Enhanced Performance Challenge: Impeller vane profiles can be a challenging shape to generate at the best of times. So when it comes to 3D modeling a range of existing castings that you would like to remanufacture, you’re going to have your work cut out for you if the plan is to…
Repair Mulwala Bridge with Minimal Disruption The bridge between the Victorian & NSW border towns of Yarrawonga and Mulwala spans a section of Lake Mulwala. The bridge opened in 1924 and is an integral part of how the two towns operate and exist on a daily basis. As the main means of crossing the Lake…
Trust Building uses 3D Scanning to Create Accurate Floor Plans for Design Team Overseas Constructed between 1914 and 1916 The Trust Building in Sydney’s CBD is heritage listed under the NSW office of Heritage and Environment and declared of state significance as a rare surviving commercial building of the Edwardian period and the leading example…
3D Scanning and 3D Printing a Triumph Badge The client needed a new badge for his customised fuel tank but wanted it to look the same as the original badge. This was the typical – I want it exactly the same but completely different. The existing badge didn’t fit the client’s new but customised fuel…
The challenge was to reproduce an approximately 60 year old cast aluminium sump and mating cover but there was a catch – It not only had to be the same, but better! This is not your average car though it’s a 1956 Maserati A6G Allemano and there’s only two in Australia. So, supply new castings that…
